Receiver Photocell Wireless 500mW

500mW Wireless Photocell - HL3-500

HL3-1 power supply not included



€695.00 tax excl.

€834.00
Tax included
check In stock
2 years warranty
Fast delivery with Chronopost
Return within 14 days

Description

The experience of TAG Heuer in the field of infrared photocells has developed highly reliable, accurate and insensitive to external influences. The novelty in 2016 is to use these cells without any wired connections. For this you only have to carry a radio receiver HL615-2 in the shift of timing to receive impulsions cells.

Principe
High frequency infra-red (32.768kHz)
Detection of signal by frequency interruption

Infra-Red Distance possible
up to 20 meters (65 ft.) with reflector (HL3-131)
up to 40 meters (130 ft.) in LOW power position
up to 80 meters (260 ft.) in HIGH power position

Output impulse
Via opto couplers and working contact / open collector

Working temperature
- 20°C to + 50°C

Internal battery
Li-Pol 3.7V 4000mAh (+ power supply 7.5V 650mA HL3-1)

Autonomy
Wireless Photocell Approx. 330 hours at 20°C
Infra-Red Transmitter LOW position: 210 hours | HIGH position: 100 hours

Precision
Fixed delay 200ms, +/- 0.5/10'000 sec (+/- 0.02 ms)

Dimensions
150 x 80 x 40 mm

Weight
800 gr

Frequency
ISM Band– 868 MHz

Power
100 mW

Range
1 km under optimal conditions, direct line of sight

Technical specifications

HL3-500
30 cm
30 cm
0.50 kg
Technical specifications
Weight
0,800
