Distant Decoder 1 input loop

The decoder provides intermediate times ("split times") on a circuit. The decoder can be connected with a RS485 network or a radio network.

Only 1 loop can be connected to this decoder.

€1,150.00
check In stock
2 years warranty
Fast delivery with Chronopost
Return within 14 days

Description

Once a passing is detected on the distant decoder it is securely reported to the main decoder. Up to 32 distant decoders can be used on your circuit.

Features :

Clock stability : Oscillator TCXO 0.5 ppm
Temperature range : -20 to 55°C (-4 to 131°F)
Dimensions : 160 x 100 x 52 mm (6.3 x 3.9 x 2 in)
Resolution : 0.001 s

Power supply :

12 VDC

Connections :

1 loop input
1 photocell input
1 manual input
1 audio output
1 AUX output
1 RS485 or RS232 output

Warranty 2 years

Technical specifications

ITSDDI
35 cm
25 cm
20 cm
1 kg
Technical specifications
Width
160 mm
Height
52 mm
Weight
600 g
Lenght
100 mm

Attachments

TS TCD IP FR

Technical Sheet - Change IP Decoder FR

Download (1.33M)
TS TCD IP EN

Technical Sheet - Change IP Decoder EN

Download (1.31M)
PS TCDDI & TCDVI FR

Product Sheet - Distant Decoder FR

Download (299.75k)
PS TCDDI & TCDVI EN

Product Sheet - Distant Decoder EN

Download (288.47k)
