ITS Flash 9+ Homologated by FIA & FIM
The ITS Flash 9+ track light is officially approved for FIA Grade 2 and FIM Grade 2, placing us among the very few companies worldwide to meet these prestigious international standards. This recognition confirms both the excellence of our in-house development and our unwavering commitment to innovation and safety in motorsport.
ITS Flash 9+ is the solution of choice for the most demanding organizations, seeking certified, robust, and scalable signalling technologies.
Power cable and whip antenna included.
Description
Designed for high-level circuits, the ITS Flash 9+ combines power, reliability, and optimal visibility in all conditions. With a fully in-house engineered electronic and software architecture, the panel delivers outstanding performance, both in responsiveness and readability.
Panel control is handled through our exclusive ITS Flash Manager software — an intuitive interface that allows real-time monitoring and operation of all units. For even greater flexibility trackside, the ITS Flash Remote Control offers instant and secure wireless operation.
The LED panel can be controlled in several ways :
- via wireless remote controls (ITSFRC, ITSFGRC, ITSFRC10)
- from ITS Flash Manager software ITSFM with the wireless Flash transmitter ITSFER
- from ITS Flash Manager software ITSFM with the wired Flash transmitter ITSFERS485
Download ITS Flash Manager software to control your displays automatically according to race events.
With the ITS Control Box 6, 15 or 32-key accessories, control the ITS Flash Manager software with greater comfort and thus gain even greater responsiveness (ITSCB6-F, ITSCB15-F, ITSCB32-F)
Caractéristiques techniques :
Type de LED : RVB
Pixel Pitch : 16 mm
Résolution face avant : 96 x 96 pixels
Résolution face arrière : 48 x 48 pixels
Densité de pixels : 2 500 pixels/m²
Angle de vision : Horizontale ± 40° / Vertical ± 15°
Luminosité : 42 000 cd/m² max (Blanc)
Surface zone affichage avant : 0.6 m²
Surface zone affichage arrière : 0.07 m²
Communication : Radio 2,4 GHz • RS-485 (2 fils)
Dimension du Panneau : 854 x 854 x 176 mm
Fixation : 4 vis M10
Poids : ~ 25 kg
Matériau du caisson : Aluminium (revêtement poudre électrostatique)
Alimentation : 220 VAC / 50 Hz
Consommation maximale : <1 000 W (Blanc)
Durée de vie des LED : 40 000 heures (sous conditions idéales)
Indice de protection : IP55
Température de fonctionnement : de -15°C à +65°C
Garantie : 2 ans
Technical specifications
Technical specifications
- Width
- 85,4 cm
- Height
- 85,4 cm
- Weight
- 25 kg
- Thickness
- 17,6 cm
