Elite Batt Transponder only

We no longer market this product.

2 years warranty
Fast delivery with Chronopost
Return within 14 days

Description

Rechargeable ELITE Transponder

Smaller, More Resistant, Lighter !

WARNING : This reference corresponds to the transponder ALONEwithout charger and without support or staple.

This transponder is the most widespread in France.

It can be used for FFSA Racing Circuit Asphalt, SuperKart FFSA and FFM Circuit Speed (Superbike, Promo Sport) ...

FFSA approved

Power supply
battery life of 4 days in full use / 18 hours of minimum charge
NiMH battery.

Technical characteristics

Max detection speed : 360 km/h (223.7 mph)
Max detection height : 2.80 m (9 ft)
Operating temperature range : -20 ° C -> 70 ° C
Dimensions : 65 x 44 x 22 mm (2.6 x 1.7 x 0.9 in)
Weight : 80 g (2.8 oz)

Bright indications :

Autonomy is shown from 1 to 4LED flashing every 10 seconds:

4 green flashing for a load of 75 to 100% battery (> = 7.5 days)
3 green flashing for a load of 50 to 75% of battery life (> = 5 days)
2 green flashing for a load of 25 to 50% of battery life (> = 2.5 days)
1 flashing green for a load of 10 to 25% of battery life (> = 1 day)
1 flashing red for a load of 0-10% burn (<24 hours)

The information level of charge is sent to the decoder when the transponder passes over the loop.

Technical specifications

ITSTEB3
25 cm
6 cm
0.08 kg
Technical specifications
Width
44 mm
Weight
80 g
Thickness
22 mm
Lenght
65 mm
